Product Description
● Directly related to the tractor's transmission system
● Different gear ratios can be selected according to customer requirements
● Energy Storage: When system pressure rises, surge oil enters the accumulator, compressing the ammonia and storing energy.
● Standby: When system pressure is stable, the accumulator maintains energy storage.
● Energy Release: When system pressure drops, the compressed ammonia expands, forcing hydraulic oil into the system to replenish flow or maintain pressure.
| Input torque (Nm) | Output torque (Nm) | Input speed (r/min) | Output speed (r/min) | Power (kW) | Weight (kg) | Transmission ratio |
| 660 | 440 | 540 | 1.5 | 810 | 37 | 16 |
| 660 | 330 | 540 | 2.0 | 1080 | 37 | 16 |
| 660 | 264 | 540 | 2.5 | 1350 | 37 | 16 |
| 660 | 220 | 540 | 3.0 | 1620 | 37 | 16 |
| 660 | 180 | 540 | 3.5 | 1836 | 37 | 16 |
| 660 | 166 | 540 | 3.8 | 2052 | 37 | 16 |
