Product Description
● Directly related to the tractor's transmission system
● Different gear ratios can be selected according to customer requirements
Its core function is to convert the standard output speed of the tractor's PTO into the optimal operating speed required by the hydraulic pump through a speed-increasing transmission.
| Input torque (Nm) | Output torque (Nm) | Input speed (r/min) | Output speed (r/min) | Power (kW) | Weight (kg) | Transmission ratio |
| 178 | 119 | 540 | 1.5 | 810 | 10 | 5.8 |
| 152 | 76 | 540 | 2.0 | 1080 | 10 | 5.8 |
| 165 | 66 | 540 | 2.5 | 1350 | 10 | 5.8 |
| 180 | 55 | 540 | 3.0 | 1680 | 10 | 5.8 |
| 186 | 58 | 540 | 3.5 | 1836 | 10 | 5.8 |
| 159 | 42 | 540 | 3.8 | 2052 | 10 | 5.8 |
