Product Description
The ZT12 Directional Control Valve is a versatile and economical monoblock valve, specifically designed for applications requiring middle-range working pressure (1-7 sections). Equipped with a built-in check valve (to prevent oil backflow), this valve ensures efficient fluid flow management. It offers a variety of control options such as manual, joy stick, cable, and more, allowing for seamless integration with different hydraulic systems. With its robust monoblock structure, the ZT12 valve provides durability and reliability, making it suitable for a wide range of applications. Upgrade your hydraulic system today with the ZT12 Directional Control Valve to experience enhanced performance and efficiency.
A hydraulic valve is a component operated by pressurized oil and is controlled by the pressure oil of a pressure regulating valve.
| Valve Structure | Monoblock Valve | Control Method | manual |
| Nominal Flow | 40 L/min | Operating Pressure | 200 bar |
| Viscosity Range | 12 CST-400CST | Operating Range | 15-75mm2/s |
| Ambient Temp | -40℃ to +80℃ | Valve Sections | 1-7 sections |
| Presure Medium | Mineral oil based hydraulic oil | Interal Leakage | 15 cc/min at 160 bar,50 ℃ |
