Product Description
The RD5100 Manual Directional Control Valve is a high-quality product that incorporates foreign advanced technology. With its customizable features, including overflow and one-way valves, this valve ensures reliable fluid control and prevents backflow. It offers flexible configuration options to suit different operating directions, and its parallel or series oil line configurations enhance versatility. Designed with tight sealing for stability and performance, the RD5100 is widely used in hydraulic systems of small loaders, forklifts, sanitation vehicles, and other construction machinery. Whether you need manual, pneumatic, or electric control, this valve delivers exceptional results, making it the ideal choice for various industries seeking efficient hydraulic control.
A hydraulic valve is a component operated by pressurized oil and is controlled by the pressure oil of a pressure regulating valve.
| Valve Structure | Monoblock Valve | Control Method | manual |
| Nominal Flow | 100 L/min | Operating Pressure | 315 bar |
| Viscosity Range | 12CST-400CST | Operating Range | 15-75mm2/s |
| Ambient Temp | -40℃ to +80℃ | Valve Sections | 1-7 sections |
| Presure Medium | Mineral oil based hydraulic oil | Interal Leakage | 15 cc/min at 160 bar,50 ℃ |
