Product Description
● Can be used as a direct replacement for Rexroth products
● A wide variety of models are available for selection
The solenoid valve consists of an electromagnet and a valve body. When powered on, it generates a magnetic field to drive the valve core to move, thereby achieving control of the fluid. It is widely used in industrial control, automation systems and other fields.
|
Model |
Specification |
Max working pressure MPa |
Max. Flow L/min |
Working voltage |
|
|
P/A/B oil ports |
T oil ports |
||||
|
4WE10-/24 |
10 |
31.5 |
21 |
120 |
12/24 DC 110/220 RAC |
|
4WE10-/220 |
10 |
31.5 |
16 |
120 |
110/220 AC |
