Product Description
● Nominal flow rate 40L/min
● Manual control, manual pneumatic control, electro-hydraulic manual control, electromagnetic control and wire control are available.
● Optional directional control for 1 to 7 spools
A hydraulic valve is a component operated by pressurized oil and is controlled by the pressure oil of a pressure regulating valve.
| Nominal Pressure (Mpa) | Max. Pressure (Mpa) | Nominal Flow (L/min) | Max Flow Rate (L/min) | Back Pressure (Mpa) | Hydranlic Oil | ||
|
Temperature Range (°C) |
Viscosity Range (mm2/s) | Filtering Accuracy (μm) | |||||
| 20 | 31.5 | 40 | 40 | ≤1 | -20 to +80 | 10-400 | ≤10 |
